Variator de viteza ATV320, 1.1 kW, 380...500 V, trifazat, compact
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products2/ATV320U11N4C-33370.jpg "Variator de viteza ATV320, 1.1 kW, 380...500 V, trifazat, compact")
BRAND: Schneider Electric
MOD DE LIVRARE: CURIER
DISPONIBILITATE: STOC LIMITAT
COD PRODUS: ATV320U11N4C
SHARE
202837 Lei
SPECIFICATII
| Certificari produs | UE |
| Certificari produs | ATEX |
| Certificari produs | NOM |
| Certificari produs | GOST |
| Certificari produs | EAC |
| Certificari produs | RCM |
| Certificari produs | KC |
| curent de scurtcircuit prezumat Isc | 5 kA |
| frecventa retea electrica | 50...60 Hz |
| puterea disipata in W | ventilator 40 W la 380 V 4 kHz |
| curent de linie | 5.0 A la 380 V (pentru sarcini grele) |
| curent de linie | 3.8 A la 500 V (pentru sarcini grele) |
| tip iesire analogica | curent configurabil soft AQ1 0...20 mA 800 Ohm, rezolutie 10 bits |
| tip iesire analogica | tensiune configurabila soft AQ1 0...10 V c.c. 470 Ohm, rezolutie 10 bits |
| deformarea maxima sub sarcina vibratorie (in timpul functionarii) | 1.5 mm la 2...13 Hz |
| Standarde | EN/IEC 61800-5-1 |
| Number of HW interfaces PROFINET | 0.0 |
| tip de iesire discreta | colector deschis DQ+ 0-1 kHz 30 V c.c. 100 mA |
| tip de iesire discreta | colector deschis DQ- 0-1 kHz 30 V c.c. 100 mA |
| profil de control al motorului asincron | raport tensiune/frecventa, 5 puncte |
| profil de control al motorului asincron | control vectorial de flux fara senzor, standard |
| profil de control al motorului asincron | raport tensiune/frecventa - economie de energie, patratic U/f |
| profil de control al motorului asincron | controlul vectorului fluxului fara senzor - Economie de energie |
| profil de control al motorului asincron | raport tensiune/frecventa, 2 puncte |
| Number of HW interfaces industrial Ethernet | 0.0 |
| curent maxim de comutatie | relay output R1A, R1B, R1C pornit rezistiv sarcina, cos phi = 1 3 A la 250 V c.a. |
| curent maxim de comutatie | relay output R1A, R1B, R1C pornit rezistiv sarcina, cos phi = 1 3 A la 30 V c.c. |
| curent maxim de comutatie | relay output R1A, R1B, R1C, R2A, R2C pornit inductiv sarcina, cos phi = 0.4 si stanga/dreapta = 7 ms 2 A la 250 V c.a. |
| curent maxim de comutatie | relay output R1A, R1B, R1C, R2A, R2C pornit inductiv sarcina, cos phi = 0.4 si stanga/dreapta = 7 ms 2 A la 30 V c.c. |
| curent maxim de comutatie | relay output R2A, R2C pornit rezistiv sarcina, cos phi = 1 5 A la 250 V c.a. |
| curent maxim de comutatie | relay output R2A, R2C pornit rezistiv sarcina, cos phi = 1 5 A la 30 V c.c. |
| varianta | standard version |
| 4 quadrant operation possible | adevarat |
| Supporting protocol for INTERBUS | fals |
| Supporting protocol for INTERBUS-Safety | fals |
| deformarea maxima sub sarcina vibratorie (in timpul transportului) | 3.5 mm at 2...13 Hz |
| formatul unitatii | compact |
| tip produs sau componenta | variator de viteza |
| Relative symmetric network frequency tolerance | 5 % |
| putere aparenta | 3.3 kVA la 500 V (pentru sarcini grele) |
| grad de protectie IP | IP20 |
| Relative symmetric mains voltage tolerance | 10 % |
| tensiunea nominala de iesire | 1.1 kW |
| EMC limit value (complied) | adevarat |
| clasa maxima a fuzibilelor asociate | 24 A |
| numar de fazein retea | 3 faze |
| greutate neta | 1.3 kg |
| cu functia de siguranta Safe Direction (SDI) | fals |
| tip releu iesire | configurable relay logic R1A 1 NO 100000 cic |
| tip releu iesire | configurable relay logic R1B 1 NC 100000 cic |
| tip releu iesire | configurable relay logic R1C |
| tip releu iesire | configurable relay logic R2A 1 NO 100000 cic |
| tip releu iesire | configurable relay logic R2C |
| 1 phase low current possible | fals |
| Permitted relative humidity (during storage) | class 1K5 according to EN 60721-3 |
| frecventa de comutare | 2...16 kHz reglabil |
| frecventa de comutare | 4...16 kHz cu |
| Supporting protocol for CAN | adevarat |
| Application in domestic and commercial area permitted | fals |
| numarul intrarii analogice | 3 |
| compensare alunecare motor | automat indiferent de sarcina |
| compensare alunecare motor | reglabil 0...300 % |
| compensare alunecare motor | indisponibilin raport tensiune/frecventa (2 sau 5 puncte) |
| Supporting protocol for MODBUS | adevarat |
| numar iesire discreta | 3 |
| Supporting protocol for DeviceNet Safety | fals |
| Protocol port de comunicatie | serial Modbus |
| Protocol port de comunicatie | CANopen |
| bucla de reglare | regulator PID reglabil |
| cu functia de siguranta Safe Position (SP) | fals |
| cu functia de siguranta Safely Limited Position (SLP) | fals |
| metoda de acces | slave CANopen |
| cu functia de siguranta Safe Operating Stop (SOS) | fals |
| Permitted relative humidity (during operation) | class 3K5 according to EN 60721-3 |
| numar intrare discreta | 7 |
| curent nominal de iesire | 3.0 A |
| Putere disipata pe dispozitiv in functie de curent | 40 W |
| aplicatie specifica produsului | masini complexe |
| Number of HW interfaces parallel | 0.0 |
| eroare de liniaritate | AI1, AI2, AI3 +/- 0.2...0.5 % din valoarea maxima pentru intrare analogica |
| eroare de liniaritate | AQ1 +/- 0.3 % pentru iesire analogica |
| Supporting protocol for BACnet | fals |
| Supporting protocol for LON | fals |
| material carcasa | plastic |
| cu functia de siguranta Safe Stop 2 (SS2) | fals |
| cu functia de siguranta Safe Stop 1 (SS1) | adevarat |
| Design of frequency changer | U converter |
| Number of input phases | 3 |
| latime | 105.0 mm |
| categorie de supratensiune | III |
| Supporting protocol for KNX | fals |
| adancime | 158.0 mm |
| tip de intrare analogica | AI1 tensiune 0...10 V c.c., impedanta: 30 kOhm, rezolutie 10 bits |
| tip de intrare analogica | AI2 tensiune diferentiala bipolara +/- 10 V c.c., impedanta: 30 kOhm, rezolutie 10 bits |
| tip de intrare analogica | AI3 curent 0...20 mA (sau 4-20 mA, x-20 mA, 20-x mA sau alte configuratii), impedanta: 250 Ohm, rezolutie 10 bits |
| Number of output phases | 3 |
| Supporting protocol for PROFIsafe | fals |
| Application in industrial area permitted | adevarat |
| Computer port | adevarat |
| Environmental class (during storage) | class 1C3 according to EN 60721-3 |
| Environmental class (during storage) | class 1S2 according to EN 60721-3 |
| clasa de mediu (in timpul functionarii) | clasa 3C3 in conformitate cu IEC 60721-3-3-3 |
| clasa de mediu (in timpul functionarii) | clasa 3S2 in conformitate cu IEC 60721-3-3-3 |
| perioada de esantionare | 2 ms (AI1, AI2, AI3) - intrare analogica |
| perioada de esantionare | 2 ms (AQ1) - iesire analogica |
| Supporting protocol for Foundation Fieldbus | fals |
| Supporting protocol for other bus systems | adevarat |
| card optional | modul de comunicare, CANopen |
| card optional | modul de comunicare, EtherCAT |
| card optional | modul de comunicare, Profibus DP V1 |
| card optional | modul de comunicare, PROFINET |
| card optional | modul de comunicare, Ethernet Powerlink |
| card optional | modul de comunicare, Ethernet/IP |
| card optional | modul de comunicare, DeviceNet |
| frecventa maxima de iesire | 0.599 kHz |
| Optical interface present | fals |
| Supporting protocol for TCP/IP | adevarat |
| Number of HW interfaces serial RS422 | 0.0 |
| cu functia de siguranta Safe brake management (SBC/SBT) | fals |
| acceleratia maxima sub sarcina vibratorie (in timpul transportului) | 10 m/s? la 13...200 Hz |
| acceleratia maxima sub sarcina de soc (in timpul transportului) | 150 m/s? la 11 ms |
| inaltime | 142.0 mm |
| temperatura ambientala de functionare | -10-60 oC |
| rampe de accelerare si decelerare | liniar |
| rampe de accelerare si decelerare | U |
| rampe de accelerare si decelerare | S |
| rampe de accelerare si decelerare | CUS |
| rampe de accelerare si decelerare | comutarea rampelor |
| rampe de accelerare si decelerare | adaptarea rampei de accelerare/decelerare |
| rampe de accelerare si decelerare | oprire automata prin injectie de c.c. pentru accelerare/decelerare |
| Encoder protocol | RS 422 |
| gama de produse | Altivar Machine ATV320 |
| acceleratia maxima in cazul unui impact de soc (in timpul functionarii) | 150 m/s? la 11 ms |
| Maximum output voltage | 500 V |
| Base load current at high overload | 22.0 A |
| Supporting protocol for AS-Interface Safety at Work | fals |
| Supporting protocol for SafetyBUS P | fals |
| grad de poluare | 2 |
| cu functia de siguranta Safe Speed Monitor (SSM) | fals |
| Supporting protocol for SERCOS | fals |
| cuplu excesiv tranzitoriu | 170-200 % cuplul nominal al motorului |
| compatibilitate electromagnetica | test de imunitate la descarcari electrostatice nivel 3 conformitate cu IEC 61000-4-2 |
| compatibilitate electromagnetica | test de imunitate la frecventa radio radiata nivel 3 conformitate cu IEC 61000-4-3 |
| compatibilitate electromagnetica | tranzienti rapizi/test de imunitate la impulsuri de ionizare nivel 4 conformitate cu IEC 61000-4-4 |
| compatibilitate electromagnetica | 1.2/50 ?s - 8/20 ?s test de imunitate la supratensiuni nivel 3 conformitate cu IEC 61000-4-5 |
| compatibilitate electromagnetica | test de imunitate la radiofrecventa condusa nivel 3 conformitate cu IEC 61000-4-6 |
| compatibilitate electromagnetica | test de imunitate la caderi de tensiune si Intreruperi conformitate cu IEC 61000-4-11 |
| temperatura ambientala de utilizare | -10-50 oC fara declasare |
| temperatura ambientala de utilizare | 50-60 oC cu |
| cu functia de siguranta Safe torque off (STO) | adevarat |
| volumul aerului de racire | 18.0 m3/h |
| Environmental class (during transport) | class 2C3 according to EN 60721-3 |
| Environmental class (during transport) | class 2S1 according to EN 60721-3 |
| Number of HW interfaces USB | 0.0 |
| marcaj | CE |
| marcaj | ATEX |
| marcaj | UL |
| marcaj | CSA |
| marcaj | EAC |
| marcaj | RCM |
| Supporting protocol for ASI | fals |
| Supporting protocol for PROFIBUS | adevarat |
| Supporting protocol for PROFINET CBA | fals |
| acceleratia maxima sub tensiune de vibratie (in timpul functionarii) | 10 m/s? la 13...200 Hz |
| Number of HW interfaces serial RS485 | 1.0 |
| precizie | +/- 0.7 % AI1, AI2, AI3 pentru temperatura -10...60 oC intrare analogica |
| precizie | +/- 0.5 % AI1, AI2, AI3 pentru temperatura 25 oC intrare analogica |
| precizie | +/- 1 % AQ1 pentru temperatura 25 oC iesire analogica |
| precizie | +/- 2 % AQ1 pentru temperatura -10...60 oC iesire analogica |
| putere motor kW | 1.1 kW pentru pentru sarcini grele |
| acceleratia maxima sub sarcina vibratorie (in timpul depozitarii) | 10 m/s? la 13...200 Hz |
| Number of HW interfaces serial RS232 | 0.0 |
| [Us] tensiune de alimentare nominala | 380...500 V |
| Supporting protocol for Data-Highway | fals |
| Curent maxim de intrare | 5.0 A |
| Supporting protocol for PROFINET IO | adevarat |
| [Us] tensiune nominala de alimentare | 380...500 V - 15...10 % |
| mod de montare | wall mount |
| Operating element present | adevarat |
| Permitted relative humidity (during transport) | class 2K5 according to EN 60721-3 |
| numarul iesirii analogice | 1 |
| grad de protectie NEMA | NEMA 1 |
| temperatura de depozitare | -25-70 oC |
| logica de intrare discreta | logica pozitiva (sursa) |
| logica de intrare discreta | logica negativa (derivatie) |
| curentul minim de comutare | relay output R1A, R1B, R1C, R2A, R2C 5 mA la 24 V c.c. |
| timp de reimprospatare | intrare logica (DI1...DI4)8 ms |
| timp de reimprospatare | relay output (R1A, R1B, R1C)2 ms |
| timp de reimprospatare | relay output (R2A, R2C)2 ms |
| Supporting protocol for DeviceNet | adevarat |
| Supporting protocol for EtherNet/IP | adevarat |
| Number of inputs, potential-free | 0 |
| Number of inputs, bidirectional, not potential-free | 0 |
| cu functia de siguranta Safe programmable logic | fals |
| Brake chopper integrated | adevarat |
| pozitie de operare | vertical +/- 10 grade |
| frecventa de comutare nominala | 4 kHz |
| Putere disipata curent static independent | 40 W |
| Supporting protocol for SUCONET | fals |
| filtru EMC | clasa C2 filtru EMC integrat |
| Capacity of DC link | 235.0 ?F |
| franare sau imobil | cu injectie c.c. |
| acceleratia maxima sub sarcina de soc (in timpul depozitarii) | 150 m/s? la 11 ms |
| tip de intrare discreta | STO cuplu de siguranta, 24 V c.c., impedanta: 1.5 kOhm |
| tip de intrare discreta | DI1...DI6 logic inputs, 24 V c.c. (30 V) |
| tip de intrare discreta | DI5 programmable as pulse input 0-30 kHz, 24 V c.c. (30 V) |
| tip de protectie | Intrerupere faza intrare variator |
| tip de protectie | supracurent Intre fazele de iesire si pamant variator |
| tip de protectie | protectie la supraincalzire variator |
| tip de protectie | scurtcircuit Intre fazele motorului variator |
| tip de protectie | protectie termica variator |
| Number of HW interfaces serial TTY | 0.0 |
| Number of HW interfaces other | 1.0 |
| cu functia de siguranta Safely Limited Speed (SLS) | adevarat |
| Ambient air transport temperature | -25-70 oC |
| deformarea maxima sub sarcina vibratorie (in timpul depozitarii) | 3.5 mm at 2...13 Hz |
| precizie viteza | +/- 10 % din alunecarea nominala 0.2 Tn la Tn |
| profil de control al motorului sincron | control vectorial fara senzori |
ÎNTREBĂRI
Distribuie produsul:
SHARE
Vezi produse similare din categorie
0 VOTURI
2387290 lei
Alți clienți au vizualizat și
0.00 (0 Review-uri)
Rețele Sociale
© Elematis 2024. Termeni si conditii.
