Modul iesiri digitale 16DO - 24 VDC 0.5A
Modul iesiri digitale 16DO - 24 VDC 0.5A - WAGO - 750-1504
BRAND: Wago
MOD DE LIVRARE: CURIER
DISPONIBILITATE: LA COMANDA
COD PRODUS: 750-1504
SHARE
Alege Culoare
SPECIFICATII
| Total number of channels (module) | 16 |
| Type of signal | Voltage |
| Type of signal voltage | DC 24 V |
| Actuator connection | 16 x (1-conductor) |
| Output characteristic | high-side switching |
| Output current per channel | 0,5 A |
| Output current | short-circuit-protected |
| Switching frequency max. | 1 kHz |
| Type of load | resistive, inductive, lamps |
| Max output data width (internal) | 16 Bit |
| System supply voltage | DC 5 V; via data contacts |
| Current consumption, system supply (5 V) | 40 mA |
| Field supply voltage | DC 24 V (-25 … +30 %); via power jumper contacts (power supply via blade contact; transmission via spring contact) |
| Current consumption, field supply (module with no external load) | 29 mA |
| Isolation | 500 V system/supply |
| Indicators | LED (1-16) green: Status DO 1 … DO 16 |
| Number of incoming power jumper contacts | 2 |
| Number of outgoing power jumper contacts | 2 |
| Current carrying capacity of the power jumper contacts | 10 A |
