PFC100 - 2ETH RS controller Wago
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/PFC100-2ETH-RS-controller-wago-7829.jpg "PFC100 - 2ETH RS controller Wago")
Element de control Wago PFC100 - 2ETH RS
BRAND: Wago
MOD DE LIVRARE: CURIER
DISPONIBILITATE: LA COMANDA
COD PRODUS: 750-8102
SHARE
Alege Culoare
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/PFC200-2-ETH-RS-Wago-controller-8636.jpg "PFC200 - 2 ETH RS Wago controller")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/controller-ethernet-G3-SD-Card-2-RJ45-2172.jpg "Controller ETHERNET - G3 SD Card 2 RJ45")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/PFC100-2-ETH-ECO-controller-Wago-2950.jpg "PFC100 - 2 ETH ECO controller Wago")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/modul-intrari-digitale-16DI-24-VDC-3ms-3574.jpg "Modul intrari digitale 16DI - 24 VDC 3ms")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/modul-iesiri-digitale-16DO-24-VDC-0-5A-5105.jpg "Modul iesiri digitale 16DO - 24 VDC 0.5A")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/modul-intrari-digitale-8DI-24-VDC-3ms-8746.jpg "Modul intrari digitale 8DI - 24 VDC 3ms")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/modul-iesiri-digitale-8DO-24-VDC-0-5A-2575.jpg "Modul iesiri digitale 8DO - 24 VDC 0.5A")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/modul-intrari-analogice-4AI-2-4-wire-SE-8619.jpg "Modul intrari analogice 4AI - 2-4-wire SE")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/modul-iesiri-analogice-4AO-2-4-wire-8394.jpg "Modul iesiri analogice 4AO - 2-4-wire")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/modul-intrari-analogice-8AI-0-4-20mA-SE-1673.jpg "Modul intrari analogice 8AI - 0/4-20mA SE")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/modul-iesiri-analogice-4AO-0-10-VDC-1345.jpg "Modul iesiri analogice 4AO - 0-10 VDC")
:contrast(5):quality(80)/https://www.elematis.ro/uploads/products/modul-capat-controller-wago-6754.jpg "Modul capat controller Wago")
SPECIFICATII
| Type of memory card | microSD up to 32 GB (all guaranteed properties only valid with WAGO 758-879/000-3102 memory card) |
| Memory card slot | Push-push mechanism, sealable cover lid |
| Number of modules per node max. | 250 |
| Number of I/O modules without bus extension max. | 64 |
| Input and output process image (internal) max. | 1000 Worte/1000 Worte |
| Input and output process image (MODBUS) max. | 32000 Worte/32000 Worte |
| Indicators | LED (SYS, RUN, I/O, USR) red/green/orange: Status system, program, internal data bus, status programmable by user (can be used via CODESYS library); LED (A, B) green: System power supply status, field supply |
| System supply voltage | DC 24 V(-25 … +30 %); via wiring level (CAGE CLAMP® connection) |
| Input current typ. at rated load (24 V) | 550 mA |
| Total current for system supply | 1.700 mA |
| Field supply voltage | DC 24 V (-25 … +30 %); via power jumper contacts |
| Current carrying capacity of the power jumper contacts | 10 A |
| Number of outgoing power jumper contacts | 3 |
| Isolation | 500 V system/supply |
